Accuracy Class	C3	C2	0.05	Units
Rated Capacities	3, 5, 10, 20 ,25, 30, 50			Tonne
Rated Output	2.0 ± 0.004			mV/V
Creep at rated output	±0.0245	±0.0245	±0.05	%FS/30min
Temperature effect on output	±0.007	±0.010	±0.025	% of applied load/5C
Temperature effect on zero	±0.007	±0.009	±0.025	% of rated output/5C
Safe Overload	150			% of rated Capacity
Ultimate overload	200			% of rated Capacity
Recommended excitation	10			Volts DC
Maximum excitation	15			Volts DC
Input impedance	800±30			Ohms
Output impedance	701.5 ±4.5			Ohms
Insulation Resistance	>5000			Megaohms
Environmental protection	IP68 (Hermetically sealed)
Cable	13 meters. 10T = 9 meter
