Accuracy Class	C3	Units
Rated Capacities	10, 20, 30, 40, 50 T	T
Rated Output	2.0 ± 0.002%	mV/V
Compensated temperature	-10 to +40	°C
Safe Overload	200	% of rated Capacity
Ultimate overload	300	% of rated Capacity
Recommended excitation	5-12	Volts DC
Maximum excitation	18	Volts DC
Input impedance	700 ± 7	Ohms
Output impedance	700 ± 7	Ohms
Insulation Resistance	>5000	Megaohms
Construction material	Nickel plated alloy steel
Environmental protection	IP68 (Hermetically sealed)
Cable	10, 20T = 12 -------30, 40, 50T = 20	Meters
